Calpeda 4HP Multi-stage Submersible Pump MXS 909 Specifications
Calpeda 4HP multi-stage submersible pump MXS 909 provides its users with efficient operation in various applications. The liquid temperature is up to 35° C and the minimum immersion depth is 100 mm, with a maximum depth of 20 m (when using the appropriate cable length). The motor operates at a frequency of 50 Hz and has a rotation speed of approximately 2900 rpm. It is a three-phase unit with a voltage range of 230-400 V. The insulation class is rated F to draw on durability and safety. It also has an IP X8 protection class, which is suitable for continuous immersion in water. This Calpeda submersible pump features a triple impregnation for humidity-proof dry winding to make it even more reliable. It has 8 impellers made from PPO-GF20 (Noryl) and a shaft constructed from chrome-nickel steel (AISI 304). The mechanical seals in this product are designed with high-quality materials for added longevity in performance. The power output is 3 kW (4 HP), with a head range of 57.5 to 105 meters, making it ideal for various pumping tasks.
| Specification | Value |
| Liquid temperature | up to 35° C |
| Minimum immersion depth | 100 mm |
| Maximum immersion depth | 20 m (with suitable cable length) |
| No. of poles | 2 |
| Frequency (Hz) | 50 |
| Rotation speed | ≈ 2900 rpm |
| Three-Phase Voltage (V) | 230-400 |
| Insulation class | F |
| Protection Class | IP X8 (for continuous immersion) |
| Humidity-proof dry winding | Triple impregnation |
| No. of impellers | 8 |
| Power (kW) | 3 |
| Power (HP) | 4 |
| Head (m) | 57.5-105 |
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Materials
- Impeller: PPO-GF20 (Noryl)
- Shaft: Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
- Upper mechanical seal: Steatite, carbon, NBR
- Lower mechanical seal: Carbone, Silicon Carbide, NBR
- Seal lubrication oil: for food machinery and pharmaceutical use oil
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Dimensions
| Dimensions (mm) | ||||
| Model | DN2 | fM | j1 | l5 |
| MXS 909 | G 1 1/4 | 853 | 7 | 133 |
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Performance Data
| m3 /h | 0 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
| l/min | 0 | 83.3 | 100 | 117 | 133 | 150 | 167 | 183 |
| H (m) | 105 | 92 | 88 | 84 | 79 | 73.5 | 67.5 | 57.5 |
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Applications
- Water supply systems
- Irrigation and drainage
- Food processing plants
- Pharmaceutical manufacturing
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Benefits
- High efficiency with low energy consumption
- Durable construction for long service life
- Versatile for various liquid types and depths
- Safe for use in food and pharmaceutical applications
Calpeda 4HP Multi-stage Submersible Pump MXS 909 Price List
| No. | Name | Price |
| 1 | Calpeda 4HP Multi-stage Submersible Pump MXS 909 Price | Contact us |
