Calpeda 2HP Multi-stage Submersible Pump MXS 904 Specifications
Calpeda 2HP multi-stage submersible pump MXS 904 is designed for efficient operation in various environments. It can handle liquid temperatures up to 35° C, which is expected for many applications. The minimum immersion depth is 100 mm, while the maximum depth reaches 20 m, provided the cable length is appropriate. This product has a frequency of 50 Hz and a rotation speed of approximately 2900 rpm to ensure optimal performance. The voltage options include single-phase at 230 V and three-phase at 230-400 V. The insulation class is rated F for safety reasons. The additional information on this Calpeda submersible pump includes its protection class, which is IP X8 for continuous immersion in water. The humidity-proof dry winding features triple impregnation for added reliability. This model also has 8 impellers made from PPO-GF20 (Noryl), and the shaft is constructed from chrome-nickel steel (AISI 304). The mechanical seals consist of high-quality materials to deliver longevity while performing. It operates at a power of 1.5 kW (2 HP) and can achieve a head of 22.5-45.5 m.
| Specification | Value | |
| Liquid temperature | up to 35° C | |
| Minimum immersion depth | 100 mm | |
| Maximum immersion depth | 20 m (with suitable cable length) | |
| No. of poles | 2 | |
| Frequency (Hz) | 50 | |
| Rotation speed | ≈ 2900 rpm | |
| Voltage (V) | single-phase | 230 |
| three-phase | 230-400 | |
| Insulation class | F | |
| Protection Class | IP X8 (for continuous immersion) | |
| Humidity-proof dry winding | Triple impregnation | |
| No. of impellers | 8 | |
| Power (kW) | 1.5 | |
| Power (HP) | 2 | |
| Head (m) | 22.5-45.5 | |
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Materials
- Impeller: PPO-GF20 (Noryl)
- Shaft: Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
- Upper mechanical seal: Steatite, carbon, NBR
- Lower mechanical seal: Carbone, Silicon Carbide, NBR
- Seal lubrication oil: for food machinery and pharmaceutical use Oil
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Dimensions and Weight
| Dimensions (mm) | Weight (kg) | ||||
| Model | DN2 | fM | j1 | l5 | |
| MPS 503 | G 1 1/4 | 573 | 7 | 133 | 16.1 |
| MPSM 503 | G 1 1/4 | 573 | 7 | 133 | 17.7 |
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Performance Data
| m3 /h | 0 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
| l/min | 0 | 83.3 | 100 | 117 | 133 | 150 | 167 | 183 |
| H (m) | 34 | 28.2 | 26.8 | 25.2 | 23.3 | 21.2 | 18.5 | 15.5 |
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Applications
- Food processing and machinery
- Pharmaceutical manufacturing
- Water treatment facilities
- Industrial cooling systems
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Benefits
- High efficiency with low energy consumption
- Durable construction for long-lasting use
- Versatile applications across industries
- Reliable performance in submerged conditions
Calpeda 2HP Multi-stage Submersible Pump MXS 904 Price List
| No. | Name | Price |
| 1 | Calpeda 2HP Multi-stage Submersible Pump MXS 904 Price | Contact us |
