Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75

0.75 kW (1 HP)

Single- and three-phase

Reviews

Download Catalogue Call Us

Quality Guarantee
Technical Advice
After Sales Service

To inquire about the price, contact the experts of Famco

Categories: Submersible Pump, Sewage pump Tags: Stream Pumps, Stream Sewage Pump, Stream Submersible Pumps

Overview of Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75

Stream 1 HP submersible sewage pump SWQD6-16-0.75 is designed for efficient water transfer in various settings. With a power of 1.0 HP, it can handle high flow rates and lift water to considerable heights. Its compact size and lightweight build make it easy to install and move around. Suitable for use in homes, farms, or small industries, it performs well in different liquid temperatures and depths. The pump’s solid passage feature helps prevent clogging, ensuring smooth operation over time. Overall, it is a reliable choice for those needing a durable and efficient water pumping solution.

Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Specifications

Stream submersible sewage pump SWQD6-16-0.75 delivers 1.0 HP (0.75 kW) of power, giving it the capability to handle a range of water transfer tasks. It comes with an outlet size of 1.5 mm and supports a maximum flow rate of 22 cubic meters per hour, equal to 366 liters per minute, offering strong volume movement when required. This Stream sewage pump reaches a maximum head of 18 meters, allowing it to lift water to notable heights. A solid passage diameter of 20 mm helps the pump move small solids without frequent blockage. The unit weighs 22.5 kg and measures 47 by 25 by 25 centimeters, giving it a form that is easy enough to transport while still feeling substantial. It can operate at immersion depths up to 5 meters and works with liquids ranging from 0 to 40 degrees Celsius. With these specifications, the pump supports residential, agricultural, and industrial settings where steady and consistent water transfer is part of the workflow.

Specification	Value
Number of phases	Single- and three-phase
Power (HP)	1.0
Power (kW)	0.75
Outlet (mm)	1.5
Maximum Flow rate (m3/h)	22
Maximum Flow rate (l/min)	366
Maximum head (m)	18
Solid passage (mm)	20
Weight (kg)	22.5
Dimensions (cm)	472525
Max.immersion depth	5 m
Liquid temperature	0~40 ℃

Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Performance Curve

Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Applications

Residential water supply and irrigation
Drainage and flood control
Industrial fluid transfer
Agricultural watering systems

Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Benefits

High flow rate for quick water transfer
Compact and lightweight design for portability
Durable construction with solid passage for solids handling
Suitable for various liquids and depths

Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Price List

No.	Name	Price
1	Stream 1 HP Submersible Sewage Pump SWQD6-16-0.75 Price	Contact us

Brand	Stream
Power (kW)	0.75
Power (HP)	1.0
Number of Phases	Single-Phase, Three-phase
Weight (kg)	22.5
Maximum Delivery Head (m)	18
Maximum immersion depth (m)	5
Maximum Liquid Temperature (°C)	40
Maximum Flow Rate (L/min)	366
Maximum Flow Rate (m3/h)	22
