Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Specifications
This product serves both professional and mild usages with a power output of 1.5 kW (2 HP). It operates efficiently in environments with ambient temperatures below 40°C. The pump can handle water with sand content up to 0.01%, hydrogen sulfide levels up to 1.5 mg/L, and chloride ion concentrations up to 400 mg/L.
It functions within a pH range of 6.5 to 8.5, so as a submersible pump it remains compatible with different water qualities. The maximum immersion depth is 70 meters. It supports both single-phase (220V) and three-phase (380V) power supplies to provide flexibility with different setups. The pump’s maximum flow rate is 80 liters per minute, or 4.8 cubic meters per hour, with a delivery head ranging from 48 to 155 meters, suitable for various elevation requirements and pressure conditions.
| Specification | Value |
| Power (kW) | 1.5 |
| Power (HP) | 2 |
| Max. ambient temperature (℃) | < 40 |
| Sand content | up to 0.01% |
| Hydrogen sulfide content | up to 1.5mg/L |
| Chloride ion content | up to 400mg/L |
| pH | 6.5 to 8.5 |
| Max. immersion depth (m) | 70 |
| Single-phase voltage (V) | 220 |
| Three-phase voltage (V) | 380 |
| Max. flow rate (l/min) | 80 |
| Max. flow rate (m3/h) | 4.8 |
| Max. delivery head (m) | 48-155 |
Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Performance Data
| M3/h | 0 | 0.6 | 1.2 | 1.8 | 2.4 | 3.0 | 3.6 | 4.2 | 4.8 |
| l/min | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | 80 |
| Head (m) | 155 | 153 | 150 | 144 | 133 | 117 | 96 | 73 | 48 |
Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Applications
- Deep well water extraction
- Irrigation systems in agriculture
- Industrial water supply
- Residential water pumping
Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Benefits
- High efficiency with 1.5 kW power output
- Suitable for deep water applications up to 70 meters
- Handles water with minimal sand and contaminants
- Flexible power options with single and three-phase support
Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Price List
| No. | Name | Price |
| 1 | Shimge 2 HP Submersible Deep Well Pump 4SG3/21 Price | Contact us |
