Pentax PM 45 Peripheral Pump Specification
Pentax PM 45 peripheral pump has power of 0.37 kW or 0.5 HP. The voltage for this peripheral pump is 230 and 400. The maximum operating pressure is 6 bar. The liquid temperature ranges from 0 to 90°C. The body of this water pump is made of cast iron. However, Pentax PM 45 BR body comprises of bronze material. The motor impeller consists of brass. The maximum head the fluid can be transferred is 40 meters.
Power | kW | 0.37 |
HP | 0.5 | |
Ampere | 1~ | 1*230 |
3~ | 3*400 | |
2-pole induction motors | 3~230/400V-50 Hz | |
1~230V-50Hz | ||
Maximum operating pressure (bar) | 6 | |
liquid temperature | 0-90° C |
Pentax PM 45 Peripheral Pump Performance Curve
Q (m3/h) | 0 | 0.3 | 0.6 | 1.2 | 1.8 | 2.4 |
Q (l/min) | 0 | 5 | 10 | 20 | 30 | 40 |
H (m) | 40 | 35 | 30 | 21 | 13 | 5 |
Pentax PM 45 Peripheral Pump Materials
- Pump body: cast iron (bronze for PM 45 BR)
- Motor bracket: cast iron (bronze for PM 45 BR)
- Impeller: brass
- Mechanical seal: ceramic-graphite-NBR
- Motor shaft: stainless steel AISI 416
Pentax PM 45 Peripheral Pump Dimensions
Model | PM 45 | PM 45 BR | PM 45 A |
A | 63 | 63 | 63 |
B | 50 | 50 | 89 |
B2 | 20 | 20 | 20 |
C | 260 | 260 | 240 |
D | 120 | 120 | 120 |
D1 | 101 | 101 | 101 |
E | 100 | 100 | 100 |
E1 | 80 | 80 | 80 |
F | 158 | 158 | 158 |
H1 | 63 | 63 | 150 |
H2 | 143 | 143 | 184 |
DNA | 1”G | ||
DNM | 1”G | ||
I | 265 | 265 | 300 |
L | 170 | 170 | 170 |
M | 175 | 175 | 195 |
Weight (kg) | 6.5 | 7 | 7.5 |
* All the dimensions are in millimeters.
Features and Benefits of Pentax PM 45 Peripheral Pump
- Compact design
- Brass impeller
- High performance
- Low noise operation
Applications of Pentax PM 45 Peripheral Pump
- Small domestic uses
- Simple industrial applications
You can buy Pentax pump PM 45 peripheral pump from us at Famcocorp. To get more information, you can contact us to help you choose the best silent single-impeller centrifugal pump.
Pentax PM 45 Peripheral Pump Price List
No | Name | Price |
1 | Pentax PM 45 single-phase peripheral pump | Contact us |
2 | Pentax PMT 45 three-phase peripheral pump | Contact us |
3 | Pentax PM 45 BR single-phase peripheral pump (bronze pump body) | Contact us |
4 | Pentax PMT 45 BR three-phase peripheral pump (bronze pump body) | Contact us |
5 | Pentax PM 45 A single-phase peripheral pump | Contact us |
6 | Pentax PMT 45 A three-phase peripheral pump | Contact us |
