Leo AJDm55/2h Single-Impeller Centrifugal Pump Specifications
The Leo AJDm75/2h single-impeller centrifugal pump is a high-performance pump designed for transferring clean water or other liquids with similar physical and chemical properties. This pump is ideal for various applications, including lifting water from wells, garden irrigation, pressure boosting for running water, and supporting equipment. Manufactured by Leo, a leading water pump manufacturer in China with stock code 002131, the AJDm55/2h ensures durability and reliability.
How does Leo AJDm55/2h Single-Impeller Centrifugal Pump Work?
The Leo AJDm55/2h operates as a deep well jet pump, utilizing a single impeller to create a centrifugal force that moves water efficiently. This water pump has a power rating of 0.55 kW (0.75 HP) and can achieve a maximum liquid temperature of +40℃, making it suitable for various domestic and commercial applications. Its robust design allows it to handle a maximum suction head (HS) of up to 30 meters, ensuring reliable performance in deep well scenarios.
Exclusive features and benefits of the Leo AJDm55/2h single-impeller centrifugal pump
- Durable Construction: The pump body and support are made from cast iron with a special rust-resistant treatment, ensuring longevity and resistance to corrosion.
- Stainless Steel Impeller: The AISI 304 stainless steel impeller provides excellent durability and resistance to wear and tear.
- AISI 304 Shaft: This high-quality shaft ensures reliable performance and a long service life.
- High Motor Quality: The pump features a motor with C&U bearings and copper winding, offering smooth and efficient operation.
- Thermal Protection: The built-in thermal protector for the single-phase motor prevents overheating and enhances safety.
- High Insulation and Protection Classes: With an insulation class of F and a protection class of IPX4, this pump is built to withstand harsh operating conditions.
- Versatile Applications: Suitable for various tasks, including well water lifting, garden irrigation, pressure boosting, and more.
Leo AJDm55/2h Single-Impeller Centrifugal Pump Installation and Usage
Follow these steps for easy installing:
- Site Preparation: Ensure a stable, level surface for installation. The pump should be placed in a dry, well-ventilated area to prevent overheating.
- Electrical Connection: Connect the pump to a power supply that matches its voltage and phase requirements. Ensure the connection is secure and meets local electrical codes.
- Water Connection: Connect the pump to the water source and ensure all connections are tight to prevent leaks.
- Priming the Pump: Before starting the pump, fill it with water to prime it. This step is crucial for preventing dry running, which can damage the pump.
- Operation: Switch on the pump and monitor its operation to ensure it is running smoothly. Check for any unusual noises or vibrations that could indicate issues.
Leo AJDm55/2h Single-Impeller Centrifugal Pump Components
The Leo AJDm55/2h is constructed from high-quality materials to ensure reliable and long-lasting performance. Here are the key components and their materials:
- Elbow: HT 200 cast iron
- Gasket Seal: NBR (nitrile rubber)
- Pump Body: HT 200 cast iron
- Diffuser: PPO (polyphenylene oxide)
- Impeller: AISI 304 stainless steel
- Mechanical Seal: Carbon/ceramic
- O-ring: NBR
- Support Cover: AISI 304/HT 200
- Bearing: High-quality ball bearing
- Rotor: Copper winding
- Venturi Tube: PPO
- Nozzle: PPO
Important Tips for Buying Leo AJDm55/2h Single-Impeller Centrifugal Pump
When considering purchasing the Leo AJDm55/2h Single-impeller centrifugal pump, it’s crucial to assess your specific needs, including the desired flow rate, head, and suction conditions. Shop around to compare prices and find the best Leo AJDm55/2h Single-impeller centrifugal pump price, as Famcocorp offers competitive pricing for this model. Ensure the specifications of Leo AJDm55/2h single-impeller centrifugal pump match your requirements by paying close attention to details such as the power rating and maximum liquid temperature.
Additionally, verify the quality of the pump by looking for high-quality components like stainless steel impellers and cast iron bodies to ensure durability and reliability. Check customer reviews and ratings to gauge the pump’s performance and reliability. Finally, ensure the pump comes with a warranty and that the manufacturer provides adequate customer support for peace of mind.
Leo AJDm55/2h Single-Impeller Centrifugal Pump Price List
| No. | Name | Price |
| 1 | Leo AJDm55/2h Single-impeller centrifugal pump price | Contact us |
