Ebara 1HP Wastewater Lift Pump Right 100 Specifications
Ebara 1HP wastewater Lift Pump Right 100 operates in single or three-phase configurations for dirty or clean water. This series of Ebara pumps handles solids up to 35 mm in size and operates efficiently at a maximum liquid temperature of 50°C. The pump can be immersed at depths ranging from 2 to 7 meters, depending on the cable length of either 5 or 10 meters. The speed of 2875 rpm and a power rating of 0.75 kW (1 HP), help it deliver a head of 2 to 10.5 meters and a maximum flow rate of 18 m³/h. The insulation class is F, while the protection degree of IPX8 provides excellent resistance to water ingress and safety. The pump operates on a frequency of 50 Hz and is compatible with both single-phase (230 V) and three-phase (400 V) power supplies. The mechanical seals on both the pump and motor sides are made from high-quality materials. The impeller is crafted from AISI 304 stainless steel, giving this wastewater pump extra resistance to corrosion and wear.
| Specification | Value |
| Type of liquid | clean and dirty water |
| Max. solids size (mm) | 35 spherical |
| Max. liquid temperature (℃) | 50 |
| Max. immersion depth (m) | 2-7 (with 5 or 10 m cable length) |
| No. of poles | 2 |
| Speed (rpm) | 2875 |
| Insulation class | F |
| Protection degree | IPX8 |
| Power rating (kW) | 0.75 |
| Power rating (HP) | 1 |
| Head (m) | 2-10.5 |
| Max. flow rate (m3/h) | 18 |
| Frequency (Hz) | 50 |
| Single-phase voltage (V) | 230 |
| Three-phase voltage (V) | 400 |
Ebara 1HP Wastewater Lift Pump Right 100 Materials
- Mechanical seal on pump side: sic/ sic/NBR
- Mechanical seal on motor side: Carbon/ceramic/NBR
- Impeller: aisi 304
Ebara 1HP Wastewater Lift Pump Right 100 Performance Curve
Ebara 1HP Wastewater Lift Pump Right 100 Applications
- Irrigation systems for agriculture
- Wastewater management in residential areas
- Draining flooded basements or construction sites
- Industrial processes requiring water transfer
Ebara 1HP Wastewater Lift Pump Right 100 Benefits
- Handles both clean and dirty water effectively
- Durable construction with corrosion-resistant materials
- High flow rate and head for efficient performance
- Versatile applications across various sectors
Ebara 1HP Wastewater Lift Pump Right 100 Price List
| No. | Name | Price |
| 1 | Ebara 1HP Wastewater Lift Pump Right 100 Price | Contact us |
