Calpeda 4HP Multi-stage Submersible Pump MXS 907 Specifications
Calpeda 4HP multi-stage submersible pump MXS 907 is designed to operate efficiently in various applications. It can handle liquid temperatures up to 35° C and has a minimum immersion depth of 100 mm, with a maximum immersion depth of 20 m when using the appropriate cable length. The motor operates at a frequency of 50 Hz and achieves a rotation speed of approximately 2900 rpm. It is a three-phase device, compatible with voltages ranging from 230 to 400 V. The insulation class is rated as F to reach durability and safety all in one. The IP X8 protection class incorporated in this product is suitable for continuous immersion in water. The humidity-proof dry winding features triple impregnation for added reliability. The pump is equipped with 8 impellers made from PPO-GF20 (Noryl) and a shaft constructed from chrome-nickel steel (AISI 304). The mechanical seals are picked from high-quality materials for effective sealing and lubrication. The power output is 3 kW (4 HP), and it can achieve a head of 47 to 81 meters, making it versatile for various pumping needs.
| Specification | Value |
| Liquid temperature | up to 35° C |
| Minimum immersion depth | 100 mm |
| Maximum immersion depth | 20 m (with suitable cable length) |
| No. of poles | 2 |
| Frequency (Hz) | 50 |
| Rotation speed | ≈ 2900 rpm |
| Three-Phase Voltage (V) | 230-400 |
| Insulation class | F |
| Protection Class | IP X8 (for continuous immersion) |
| humidity-proof dry winding | Triple impregnation |
| No. of impellers | 8 |
| Power (kW) | 3 |
| Power (HP) | 4 |
| Head (m) | 47-81 |
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Materials
- Impeller: PPO-GF20 (Noryl)
- Shaft: Chrome-nickel steel 1.4301 EN 10088 (AISI 304)
- Upper mechanical seal: Steatite, carbon, NBR
- Lower mechanical seal: Carbon, Silicon Carbide, NBR
- Seal lubrication oil: for food machinery and pharmaceutic use Oil
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Dimensions
| Dimensions (mm) | ||||
| Model | DN2 | fM | j1 | l5 |
| MXS 905 | G 1 1/4 | 738 | 7 | 133 |
| MXSM 905 | G 1 1/4 | 738 | 7 | 133 |
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Performance Data
| m3 /h | 0 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
| l/min | 0 | 83.3 | 100 | 117 | 133 | 150 | 167 | 183 |
| H (m) | 81 | 71 | 68.5 | 66 | 62 | 58 | 53 | 47 |
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Applications
- Industrial liquid transfer
- Pharmaceutical manufacturing processes
- Water treatment facilities
- Food processing operations
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Benefits
- High efficiency with multiple impellers for better flow
- Durable construction with corrosion-resistant materials
- Safe operation in continuous immersion conditions
- Versatile applications across various industries
Calpeda 4HP Multi-stage Submersible Pump MXS 907 Price List
| No. | Name | Price |
| 1 | Calpeda 4HP Multi-stage Submersible Pump MXS 907 Price | Contact us |
