Speroni 1.5 HP Multistage Submersible Pump SX 70-18

1.1 kW (1.5 HP)

Single-phase

Reviews

Download Catalogue Call Us

Quality Guarantee
Technical Advice
After Sales Service

To inquire about the price, contact the experts of Famco

Category: Submersible Pump Tags: Speroni Pumps, Speroni Submersible Pumps

Overview of Speroni 1.5 HP Multistage Submersible Pump SX 70-18

The SX 70-18 is a handy 1.5 HP solution in submerged conditions of up to 150-meter deep, with its head height reaching 116 meters, and flow rates as high as 70 l/min. Its robust stainless steel construction ensures durability and resistance to corrosion. With 18 stages, it provides high pressure and efficiency, suitable for demanding environments. The compact design and lightweight build make it easy to install and operate, even in challenging conditions. It can handle liquids with moderate sand content and temperature, making it versatile for different water qualities. Overall, this pump offers reliable performance for long-term use in both residential and industrial settings.

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Specifications

This SX series Speroni pump features a powerful 1.5 HP (1.1 kW) motor, designed for efficient water transfer and high performance. It has a maximum flow rate of 70 liters per minute and can generate a delivery head of up to 116 meters, making it suitable for various demanding applications. The pump includes 18 stages, which help in achieving high pressure and flow efficiency. It can operate at a maximum immersion depth of 150 meters, allowing deep water extraction or transfer. The device is built with durable stainless steel AISI 304 for the external casing, motor shaft, and impellers, ensuring this Speroni submersible pump stays resistant to corrosion and long-term use. It is capable of handling liquids with a temperature up to 35°C and sand content up to 50 g/m³, making it versatile for different water qualities. The pump weighs only 4.7 kg, making it relatively lightweight and easy to install or move as needed. Overall, this pump is ideal for applications requiring high pressure, deep immersion, and durability in challenging environments.

Speroni 1.5 HP Multistage Submersible Pump SX 70-18

Specification	Value
Power (HP)	1.5
Power (kW)	1.1
Max. flow rate (l/min)	70
Max. delivery head (m)	116
Number of stages	18
Max. immersion depth (m)	150
Max. liquid temperature (°C)	35
Sand content (g/m³)	50
External casing	stainless steel AISI 304
Motor shaft	stainless steel AISI 304
Stages and impellers	stainless steel AISI 304
Weight (kg)	4.7

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Performance Data

m³/h	0	1.5	1.8	2.1	2.4	2.7	3	3.6	4.2
l/min	0	25	30	35	40	45	50	60	70
head (m)	116	101	97	94	90	85	80	67	45

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Performance Curve

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Applications

Deep well water extraction
Irrigation systems
Industrial water transfer
Municipal water supply

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Benefits

High efficiency with 18 stages for strong pressure
Durable stainless steel construction for corrosion resistance
Lightweight and easy to install
Capable of operating at significant depths up to 150 meters

Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Price List

No.	Name	Price
1	Speroni 1.5 HP Multistage Submersible Pump SX 70-18 Price	Contact us

Brand	Speroni
Applications	Agriculture, Deep well water extraction, Domestic, Civil, Industrial
Power (kW)	1.1
Power (HP)	1.5
Maximum Flow Rate (L/min)	70
Maximum Delivery Head (m)	116
