Sistema 3 HP Multistage Submersible Water Pump ST-40-13

Sistema 3 HP Multistage Submersible Pump ST 40-13

2.2 kW (3 HP)

Single-phase

Reviews

Download Catalogue Call Us

Quality Guarantee
Technical Advice
After Sales Service

To inquire about the price, contact the experts of Famco

Category: Submersible Pump Tags: Sistema Pumps, Sistema Submersible Pump

Overview of Sistema 3 HP Multistage Submersible Pump ST 40-13

This product is a powerful and durable pump designed for deep water applications. With a robust 2.2 kW motor, it can move large volumes of liquid efficiently. Its high maximum flow rate and head height make it ideal for tasks like water transfer, drainage, and industrial processes. The device’s lightweight design and high protection rating ensure it performs well even in tough conditions, including deep immersion and high liquid temperatures. It is suitable for use in various fields such as water treatment, irrigation, and industrial fluid management, providing reliable and consistent operation in demanding environments.

Sistema 3 HP Multistage Submersible Pump ST 40-13 Specifications

This product features a power output of 2.2 kW, equivalent to 3 HP, making it suitable for various demanding applications. It can handle a maximum flow rate of 12 cubic meters per hour, which translates to 200 liters per minute, ensuring efficient fluid movement. The maximum head height it can achieve is 82 meters, allowing it to operate effectively in deep environments. The device weighs 5.5 kilograms, making it relatively lightweight and easy to handle. This Sistema submersible pump is designed for deep immersion, with a maximum depth capacity of 150 meters, and can operate in liquids at temperatures up to 35°C. The insulation class is F, indicating good thermal insulation properties, and it has an IP68 protection rating, meaning it is dust-tight and protected against continuous immersion in water. These specifications make the product highly durable and suitable for various industrial and water management tasks, especially in challenging environments requiring reliable performance under water and high pressure.

Specification	Value
Power (kW)	2.2
Power (HP)	3
Maximum Flow rate (m3/h)	12
Maximum Flow rate (l/min)	200
Maximum head (m)	82
Weight (kg)	5.5
Maximum depth of immersion	150mt
Liquid temperature (°C)	35
Insulation class	F
Protection class	IP68

Sistema 3 HP Multistage Submersible Pump ST 40-13 Performance Data

Q (m3/h)	0	4.8	5.4	6	7.2	8.4	9.6	10.8	12
Q (l/min)	0	80	90	100	120	140	160	180	200
H (m)	52	48	47	46	43	39	35	29	24

Sistema 3 HP Multistage Submersible Pump ST 40-13 Applications

Water transfer and pumping in industrial settings
Deep well and borehole water extraction
Irrigation systems for agriculture
Drainage and flood control projects

Sistema 3 HP Multistage Submersible Pump ST 40-13 Benefits

High efficiency with a maximum flow rate of 200 l/min
Suitable for deep immersion up to 150 meters
Durable construction with IP68 protection and F insulation class
Lightweight and easy to handle for quick installation

Sistema 3 HP Multistage Submersible Pump ST 40-13 Price List

No.	Name	Price
1	Sistema 3 HP Multistage Submersible Pump ST 40-13 Price	Contact us

Brand	Sistema
Power (HP)	3
Power (kW)	2.2
Maximum Flow Rate (L/min)	200
Maximum Flow Rate (m3/h)	12
Maximum Delivery Head (m)	82
Weight (kg)	5.5
Maximum immersion depth (m)	150
Maximum Liquid Temperature (°C)	35
Insulation Class	F
Degree of Protection	IP68
