Shimge 5.5 HP Submersible Pump 4SP6/34-4 Specifications
The 4SP6/34-4 is a Shimge product, designed for various environmental conditions, with a maximum ambient temperature of less than 40°C. It can handle water with sand content up to 100 grams per cubic meter, making this Shimge submersible pump suitable for diverse water sources. The device can tolerate hydrogen sulfide levels up to 1.5 milligrams per liter and chloride ion concentrations up to 400 milligrams per liter, ensuring reliable performance in different water qualities. It functions within a pH range of 6.5 to 8.5, maintaining stability across typical water pH levels. The maximum immersion depth is 70 meters, allowing deep water extraction. It operates on a three-phase voltage of 380 volts, ideal for industrial applications. Installation is straightforward in 4-inch boreholes. The motor power is 4 kilowatts, equivalent to 5.5 horsepower, providing sufficient power for demanding tasks. The maximum flow rate is 70 liters per minute, suitable for various water transfer needs. The head range varies from 223 to 98 meters, with a maximum head of 241 meters, making it versatile for different pumping requirements.
| Specification | Value |
| Max. ambient temperature | < 40°C |
| Maximum sand content | 100g/m³ |
| Maximum Hydrogen sulfide content | up to 1.5mg/L |
| Maximum chloride ion content | up to 400mg/L |
| pH range | 6.5 to 8.5 |
| Max. immersion depth | 70 meters |
| Three-phase voltage | 380V |
| Installation | in 4-inch boreholes |
| Power | 4 kW |
| Power (HP) | 5.5 HP |
| Max. flow rate | 70 liters per minute |
| Head range | 223-98 meters |
| Max. head | 241 meters |
Shimge 5.5 HP Submersible Pump 4SP6/34-4 Performance Data
| m³/h | 0 | 1.2 | 2.4 | 3.6 | 4.8 | 6 | 7.2 | 8.4 | head range (m) |
| l/min | 0 | 10 | 20 | 30 | 40 | 50 | 60 | 70 | |
| head (m) | 241 | 225 | 219 | 201 | 178 | 153 | 120 | 78 | 223-98 |
Shimge 5.5 HP Submersible Pump 4SP6/34-4 Applications
- Deep well water extraction for industrial use
- Agricultural irrigation systems
- Municipal water supply projects
- Water transfer in challenging environments
Shimge 5.5 HP Submersible Pump 4SP6/34-4 Benefits
- High efficiency in deep water pumping
- Durable construction for tough conditions
- Easy installation in boreholes
- Reliable performance with various water qualities
Shimge 5.5 HP Submersible Pump 4SP6/34-4 Price List
| No. | Name | Price |
| 1 | Shimge 5.5 HP Submersible Pump 4SP6/34-4 Price | Contact us |
