Shimge 4 HP Submersible Pump 4SP6/26-3

3 kW (4 HP)

Three-phase

Reviews

Download Catalogue Call Us

Quality Guarantee
Technical Advice
After Sales Service

To inquire about the price, contact the experts of Famco

Category: Submersible Pump Tags: Shimge Pumps, Shimge Submersible Pumps

Overview of Shimge 4 HP Submersible Pump 4SP6/26-3

This 4 HP Shimge produced submersible pump has flow rates of up to 70 l/min. It is suitable for use in various water conditions, including those with sand, hydrogen sulfide, and chloride ions. The pump is built to operate efficiently at high depths and flow rates, making it perfect for industrial, agricultural, or municipal water supply needs. This three-phase compatible submersible pump has a solid construction that comes in handy in difficult environments. Easy to install in 4-inch boreholes, it provides a steady and powerful water flow, supporting large-scale water distribution systems. The pump’s ability to handle different water qualities and depths makes it a versatile choice for many water management projects.

Shimge 4 HP Submersible Pump 4SP6/26-3 Specifications

The 4SP6/26-3 Shimge pump operates efficiently under ambient temperatures below 40°C and can handle water with sand content up to 100 grams per cubic meter. It is designed to work with water containing hydrogen sulfide levels up to 1.5 milligrams per liter and chloride ions up to 400 milligrams per liter. The device functions within a pH range of 6.5 to 8.5, ensuring compatibility with various water qualities. It can be immersed up to 70 meters deep, making it suitable for deep well applications. Powered by a three-phase 380-volt system, it delivers a power output of 3 kilowatts (equivalent to 4 horsepower). The installation of this Shimge submersible pump requires a 4-inch borehole, providing a stable setup. It can pump water at a maximum flow rate of 70 liters per minute, with a head range from 75 to 172 meters, and a maximum head capacity of 185 meters, making it ideal for high-demand water supply systems.

Specification	Value
Max. ambient temperature	< 40°C
Maximum sand content	100g/m³
Maximum Hydrogen sulfide content	up to 1.5mg/L
Maximum chloride ion content	up to 400mg/L
pH	6.5 to 8.5
Max. immersion depth (m)	70
three-phase voltage (V)	380
installation	in 4-inch boreholes
power (kW)	3
power (HP)	4
Max. flow rate (l/min)	70
head range (m)	172-75
max. head (m)	185

Shimge 4 HP Submersible Pump 4SP6/26-3 Performance Data

m³/h	0	1.2	2.4	3.6	4.8	6	7.2	8.4	head range (m)
l/min	0	10	20	30	40	50	60	70	head range (m)
head (m)	185	173	169	156	138	117	92	60	172-75

Shimge 4 HP Submersible Pump 4SP6/26-3 Applications

Deep well water extraction for industrial use
Agricultural irrigation systems
Municipal water supply projects
Water treatment plants

Shimge 4 HP Submersible Pump 4SP6/26-3 Benefits

High efficiency at deep depths
Suitable for water with sand and chemical content
Reliable performance with stable power supply
Easy installation in standard boreholes

Shimge 4 HP Submersible Pump 4SP6/26-3 Price List

No.	Name	Price
1	Shimge 4 HP Submersible Pump 4SP6/26-3 Price	Contact us

Brand	Shimge
Applications	Deep well water extraction, Municipal water supply, Water Supply Connections
Power (kW)	3
Power (HP)	4
Maximum Flow Rate (L/min)	70
Maximum Delivery Head (m)	185
