Shimge 3 HP Submersible Pump 4SP6/20-2.2

2.2 kW (3 HP)

Single-phase or three-phase

Reviews

Download Catalogue Call Us

Quality Guarantee
Technical Advice
After Sales Service

To inquire about the price, contact the experts of Famco

Category: Submersible Pump Tags: Shimge Pumps, Shimge Submersible Pumps

Overview of Shimge 3 HP Submersible Pump 4SP6/20-2.2

The 4SP6/20-2.2 supports water movement tasks that require up to 70 l/min flow rates and heads of about 140 meters. It is suitable for environments with specific chemical and physical water conditions, including sand and sulfide content. Its construction allows for installation in boreholes up to 70 meters deep. The pump is versatile, supporting different voltage configurations, and provides a steady flow rate suitable for residential, agricultural, or industrial use. Its high head capacity makes it ideal for situations requiring significant water elevation, ensuring efficient and reliable operation in challenging conditions. This Shimge pump is available with compatible modes to two setups:

Shimge 3 HP Submersible Pump 4SPm6/20-2.2 (single-phase)

Shimge 3 HP Submersible Pump 4SP6/20-2.2 (three-phase)

Shimge 3 HP Submersible Pump 4SP6/20-2.2 Specifications

This product operates efficiently in environments with a maximum ambient temperature of less than 40°C. It can handle sand content up to 100 grams per cubic meter and withstand hydrogen sulfide levels up to 1.5 milligrams per liter. The device is suitable for water with chloride ion concentrations up to 400 milligrams per liter and maintains optimal performance within a pH range of 6.5 to 8.5. It is designed for installation in boreholes with a diameter of 4 inches and can be submerged up to 70 meters deep. The 4SP6/20-2.2 Shimge submersible pump has the capacity to support both single-phase voltage of 220 volts and three-phase voltage of 380 volts, making it versatile for different power setups. It consumes 2.2 kilowatts, equivalent to 3 horsepower, and can deliver a maximum flow rate of 70 liters per minute. The head range varies from 135 meters to 55 meters, with a maximum head capacity of 142 meters, ensuring reliable water pumping across various applications.

Specification	Value
Max. ambient temperature	< 40°C
Maximum sand content	100g/m³
Maximum Hydrogen sulfide content	up to 1.5mg/L
Maximum chloride ion content	up to 400mg/L
pH	6.5 to 8.5
Max. immersion depth (m)	70
single-phase voltage (V)	220
three-phase voltage (V)	380
installation	in 4-inch boreholes
power (kW)	2.2
power (HP)	3
Max. flow rate (l/min)	70
head range (m)	135-55
max. head (m)	142

Shimge 3 HP Submersible Pump 4SP6/20-2.2 Performance Data

m³/h	0	1.2	2.4	3.6	4.8	6	7.2	8.4	head range (m)
l/min	0	10	20	30	40	50	60	70	head range (m)
head (m)	142	136	132	123	108	90	72	45	135-55

Shimge 3 HP Submersible Pump 4SP6/20-2.2 Applications

Deep well water extraction for residential use
Irrigation systems in agriculture
Industrial water supply systems
Municipal water treatment facilities

Shimge 3 HP Submersible Pump 4SP6/20-2.2 Benefits

Handles high sand and sulfide levels effectively
Supports versatile voltage options for easy installation
Provides high head capacity for deep water sources
Reliable performance in demanding environments

Shimge 3 HP Submersible Pump 4SP6/20-2.2 Price List

No.	Name	Price
1	Shimge 3 HP Submersible Pump 4SP6/20-2.2 Price	Contact us

Brand	Shimge
Applications	Industrial water transfer, Irrigation, Water Transfer and Supply
Power (kW)	2.2
Power (HP)	3
Maximum Flow Rate (L/min)	70
Maximum Delivery Head (m)	142
