Saer 3 HP Water-filled Submersible Motor CL95-3 (3kN) Specifications
This product features a power output of 2.2 kW, equivalent to 3 HP, suitable for various demanding applications. It operates within a voltage range of 230 to 400 volts, accommodating both single-phase and three-phase power supplies. The current draw is 14.4 amperes for single-phase setups and 5.8 amperes for three-phase configurations, making it versatile for different electrical systems. The motor runs at a speed of 3000 RPM, ensuring efficient performance. Its efficiency ratings are 72% for single-phase and 77% for three-phase, indicating reliable energy use. The power factor is 0.9 for single-phase and 0.7 for three-phase, which helps in reducing energy losses. Designed to work in liquids at a maximum temperature of 35°C, it can operate at depths up to 200 meters underwater. The device boasts an IP68 protection degree, making it highly resistant to dust and water ingress, suitable for harsh environments. Additionally, it has an insulation class of F, ensuring safety and durability during prolonged use.
| Specification | Value |
| Power (kW) | 2.2 |
| Power (HP) | 3 |
| Voltage (V) | 230-400 |
| Current (A) | 14.4 (Single-phase), 5.8 (Three-phase) |
| Speed (RPM) | 3000 |
| Efficiency (η) | 72 (Single-phase), 77 (Three-phase) |
| Power factor (Cosφ) | 0.9 (Single-phase), 0.7 (Three-phase) |
| Liquid temperature (°C) | 35 |
| Max immersion depth | 200 m |
| Protection degree | IP68 |
| Insulation class | F |
Saer 3 HP Water-filled Submersible Motor CL95-3 (3kN) Applications
- Water pumping systems
- Industrial liquid transfer
- Deep well applications
- Aquaculture and water treatment
Saer 3 HP Water-filled Submersible Motor CL95-3 (3kN) Benefits
- High efficiency reduces energy costs
- Deep immersion capability up to 200 meters
- Robust IP68 protection for harsh environments
- Flexible voltage and phase options
Saer 3 HP Water-filled Submersible Motor CL95-3 (3kN) Price List
| No. | Name | Price |
| 1 | Saer 3 HP Water-filled Submersible Motor CL95-3 (3kN) Price | Contact us |
