Saer 1.5 HP Submersible Pump NS-95A/24 Specifications
Saer submersible pump NS-95A/24 has a power output of 1.1 kW (1.5 HP) and suits a variety of pumping tasks. It operates within a voltage range of 230 to 400 volts and supports both single-phase and three-phase power supplies, with current ratings of 9.6 A for single-phase and 2.9 A for three-phase operation. This Saer submersible pump delivers a flow rate of 3.2 cubic meters per hour, equivalent to 53.3 liters per minute, appropriate for medium-scale liquid transfer. The maximum head reaches 122 meters, which supports strong vertical lift performance. The pump works with liquids at temperatures from 0°C to 35°C and supports a maximum working pressure of 34 bar. It can operate at immersion depths of up to 300 meters below the liquid level, suitable for deep-water and submersible installations in demanding environments.
| Specification | Value |
| Power (kW) | 1.1 |
| Power (HP) | 1.5 |
| Voltage (V) | 230-400 |
| Current (A) | 2.9 (three-phase), 9.6 (single-phase) |
| Flow rate (m3/h) | 3.2 |
| Flow rate (l/min) | 53.3 |
| Maximum head (m) | 122 |
| Liquid Temperature | min 0°C, max 35°C |
| Maximum working pressure | 34 bar |
| Maximum immersion depth | 300 m under liquid level |
Saer 1.5 HP Submersible Pump NS-95A/24 Performance Data
| Q (m3/h) | 0 | 13,3 | 16,7 | 20,8 | 26,7 | 33,3 | 41,7 | 3.2 |
| Q (l/min) | 0 | 0,8 | 1 | 1,25 | 1,6 | 2 | 2,5 | 53.3 |
| H (m) | 122 | 119 | 118 | 116 | 113 | 104 | 91 | 67 |
Saer 1.5 HP Submersible Pump NS-95A/24 Applications
- Deep well water extraction
- Irrigation systems
- Industrial liquid transfer
- High-pressure water supply
Saer 1.5 HP Submersible Pump NS-95A/24 Benefits
- High maximum head for deep water applications
- Flexible voltage and phase options
- Durable construction for demanding environments
- Efficient flow rate suitable for various tasks
Saer 1.5 HP Submersible Pump NS-95A/24 Price List
| No. | Name | Price |
| 1 | Saer 1.5 HP Submersible Pump NS-95A/24 Price | Contact us |
