Kubota 13.2 kVA Diesel Generator Set J112 Specifications
This generator offers a prime power output of 12 kVA (12 kW) and a standby power of 13.2 kVA (13.2 kW). It operates at 50 Hz frequency with a single-phase voltage of 220V and a power factor of 1. The engine is a water-cooled, 4-cycle type with 3 cylinders and a displacement of 1.001 liters, running at 3000 rpm. This series of Kubota diesel generator sets features insulation classes F for the rotor coil and B for the stator coil. The generator’s dimensions are 1215 mm in length, 611 mm in width, and 922 mm in height, with a net weight of approximately 340 kg. It has a fuel tank capacity of 79 liters, providing up to 17 hours of operation at full load, and consumes about 4.6 liters of fuel per hour under full load. The sound level at full load is 76.5 dB(A). It includes safety features like an emergency stop system triggered by abnormal oil pressure, water temperature, or fan belt issues.
| Specification | Value | |
| Power Output | Prime (kVA) | 12 |
| Prime (kW) | 12 | |
| Standby (kVA) | 13.2 | |
| Standby (kW) | 13.2 | |
| Frequency (Hz) | 50 | |
| Single-phase Voltage (V) | 220 | |
| Power Factor | 1 | |
| Number of Poles | 2 | |
| Insulation Class | Rotor coil | class F |
| Stator coil | class B | |
| Engine Type | Water-cooled, 4-cycle | |
| Number of Cylinders | 3 | |
| Displacement (L) | 1.001 | |
| Engine Speed (rpm) | 3000 | |
| Continuous Rated Output (kW) | 14.4 | |
| Oil Capacity (L) | 4.3 | |
| Coolant Capacity (L) | 3.3 | |
| Fuel Consumption (L/h) | at Full Load | 4.6 |
| at 3/4 Load | 3.7 | |
| at 1/2 Load | 3.0 | |
| at 1/4 Load | 2.4 | |
| Fuel Tank Capacity (L) | 79.0 | |
| Operation Hours | at Full Load | 17.0 |
| at 3/4 Load | 21.2 | |
| at 1/2 Load | 26.1 | |
| at 1/4 Load | 33.5 | |
| Sound Level at Full Load (dB(A)) | 76.5 | |
Kubota 13.2 kVA Diesel Generator Set J112 Dimensions and Weight
| Dimensions (L x W x H) mm | 1215 x 611 x 922 |
| Approx. Net Weight (kg) | 340 |
Kubota 13.2 kVA Diesel Generator Set J112 Applications
- Construction sites for powering tools and equipment
- Emergency backup for homes and businesses
- Outdoor events and festivals
- Industrial and manufacturing facilities
Kubota 13.2 kVA Diesel Generator Set J112 Benefits
- High power output suitable for various needs
- Long operation hours with large fuel tank
- Durable water-cooled engine for reliability
- Low noise level for quieter operation
Kubota 13.2 kVA Diesel Generator Set J112 Price List
| No. | Name | Price |
| 1 | Kubota 13.2 kVA Diesel Generator Set J112 Price | Contact us |
There are no reviews yet.
