Elemax 8.8 kW Diesel Portable Generator SH11D Specifications
This generator features a 3-cylinder Kubota engine operating at 3000 rpm, designed for power supply. It supports both 50 Hz and 60 Hz frequencies, making it versatile for various regions. The unit provides a maximum power output of 8.8 kVA and 8.8 kW, suitable for demanding applications. It operates on a single-phase voltage of 220 or 240 volts, with a power factor of 1, ensuring efficient energy use. The SH11D Elemax diesel portable generator has a compact size of 1281 mm in length, 618 mm in width, and 698 mm in height, and weighs approximately 295 kg. It includes an electric start system for easy operation, and the control panel is equipped with essential gauges like a voltmeter, hour meter, and pilot lamp for monitoring.
The fuel tank holds 28 liters, with a consumption rate of 3.2 liters per hour at full load and 2.1 liters at half load, providing extended operation times. Engineers have prioritized safety features in making this Elemax generator, using an emergency stop system that shuts down the engine if abnormal conditions are detected, like oil pressure or water temperature issues. The generator is considered to be silent, producing a sound level of 68 dB at a 7-meter distance, ensuring quieter operation suitable for various environments.
| Specification | Value | |
| frequency | 50, 60 Hz | |
| maximum power output | 8.8 kVA / 8.8 kW | |
| rated single-phase voltage | 220, 240 V | |
| number of poles | 2 | |
| power factor | 1 | |
| engine maker | Kubota | |
| number of cylinders | 3 | |
| continuous operation hours at full load | 8.5 hours | |
| continuous operation hours at half load | 13.3 hours | |
| engine speed | 3000 rpm | |
| starting system | electric starter | |
| control panel includes | pilot lamp, volt meter, hour meter | |
| fuel tank capacity | 28 liters | |
| fuel consumption | at full load | 3.2 liters/hour |
| at half load | 2.1 liters/hour | |
| sound level at full load/7m distance | 68 dB | |
Elemax 8.8 kW Diesel Portable Generator SH11D Dimensions and Weight
| dimensions | 1281*618*698 mm |
| approximate wet net weight | 295 kg |
Elemax 8.8 kW Diesel Portable Generator SH11D Applications
- Backup power for homes and businesses
- Construction sites and outdoor projects
- Emergency power supply during outages
- Event and outdoor activity power needs
Elemax 8.8 kW Diesel Portable Generator SH11D Benefits
- Reliable power with a durable Kubota engine
- Long operation hours at half load
- Easy to operate with electric start and monitoring gauges
- Quiet operation suitable for various environments
Elemax 8.8 kW Diesel Portable Generator SH11D Price List
| No. | Name | Price |
| 1 | Elemax 8.8 kW Diesel Portable Generator SH11D Price | Contact us |
There are no reviews yet.
