Ebara 50 HP Wastewater Lift Pump 300DL537 Specifications
This sewage pump is designed to handle dirty liquids with solids up to 70 mm in size. It operates at a maximum temperature of 40°C and can be submerged up to 7 meters deep. The pump features a durable cast-iron casing and impeller, ensuring long-lasting performance in demanding environments. It uses high-quality mechanical seals on both the impeller and motor sides, with materials like SiC, ceramic, NBR, and carbon to prevent leaks and withstand wear. The Ebara submersible pumps in the DL line have 4-pole motors, running at 1450 rpm, with an insulation class F for safety and efficiency. Its protection degree is IP68, making it suitable for continuous submersion. The presented Ebara sewage pump runs on a 50 Hz power supply with voltage options of 380-415V or 400-415V. It delivers a maximum flow rate of 12,000 liters per minute and can achieve a head height of up to 40 meters, making it ideal for various sewage and wastewater applications. The motor power is 37 kW, equivalent to 50 HP, providing robust performance for demanding tasks. Overall, this pump combines durability, efficiency, and high capacity, making it more than suitable for industrial and municipal sewage systems.
| Specification | Value |
| Type of liquid | sewage |
| Max. temperature (°C) | 40 |
| Max. solids size (mm) | 70 |
| Max. immersion depth (m) | 7 |
| Casing material | cast iron |
| Impeller | cast iron |
| Mechanical seal on impeller side | SiC/SiC/NBR |
| Mechanical seal on motor side | Carbon/Ceramic/NBR |
| Number of poles | 4 |
| Rotation speed (rpm) | 1450 |
| Insulation class | F |
| Protection degree | IP68 |
| Frequency (Hz) | 50 |
| Voltage (V) | 380-415, 400-415 |
| Power (kW) | 37 |
| Power (HP) | 50 |
| Max. flow rate (l/min) | 12000 |
| Max. head height (m) | 40 |
Ebara 50 HP Wastewater Lift Pump 300DL537 Performance Data
| l/min | 0 | 3000 | 4000 | 5000 | 6000 | 7000 | 8000 | 9000 | 10000 | 11000 | 12000 | 13000 |
| m³/h | 0 | 180 | 240 | 300 | 360 | 420 | 480 | 540 | 600 | 660 | 720 | 780 |
| Head (m) | 45 | – | 35 | 33.1 | 31 | 28.6 | 26.1 | 23.5 | 20.8 | 17.9 | 14.8 | 11.3 |
Ebara 50 HP Wastewater Lift Pump 300DL537 Dimensions
| Dimensions (mm) | Weight (kg) | |||||||||
| A | B | C | D | E | F | H | J | L1 | CL (m) | 522 |
| 1172 | 660 | 838 | 335 | 615 | 726 | 1336 | 460 | 585 | 10 | |
Ebara 50 HP Wastewater Lift Pump 300DL537 Applications
- Municipal sewage treatment plants
- Industrial wastewater management
- Commercial building sewage systems
- Flood control and drainage projects
Ebara 50 HP Wastewater Lift Pump 300DL537 Benefits
- High capacity for large volume sewage transfer
- Durable cast iron construction for long-term use
- Reliable mechanical seals prevent leaks
- Suitable for continuous submersion with IP68 protection
