Ebara 20 HP Wastewater Lift Pump 300DL515 Specifications
This sewage pump is designed to handle dirty liquids with solids up to 70 mm in size. It operates efficiently at a maximum temperature of 40°C and can be submerged up to 7 meters deep. The pump features a durable cast iron casing and impeller, ensuring long-lasting performance even in tough environments. Looking for an all-time Ebara sewage pump with good protection against ingress and corrosion? This one definitely checks this box by using high-quality mechanical seals on both the impeller and motor sides, with materials like SiC, ceramic, NBR, and carbon. The motor has 4 poles, running at 1450 rpm, and is rated for an insulation class F, suitable for continuous operation. Its protection degree is IP68, making this line of Ebara submersible pumps as protected as possible against dust and water ingress. The pump operates on a 50 Hz frequency with a voltage range of 380-415V, making it compatible with standard industrial power supplies. It delivers a maximum flow rate of 11,000 liters per minute and can lift water up to 12.2 meters high, making it suitable for various sewage and wastewater applications. The power output is 15 kW or 20 HP, providing robust performance for demanding tasks. Overall, this pump is ideal for sewage transfer, drainage, and wastewater management in industrial or municipal settings.
Specification | Value |
Type of liquid | sewage |
Max. temperature (° C) | 40 |
Max. solids size (mm) | 70 |
Max. immersion depth (m) | 7 |
Casing material | cast iron |
Impeller | cast iron |
Mechanical seal on impeller side | SiC/SiC/NBR |
Mechanical seal on motor side | Carbon/Ceramic/NBR |
Number of poles | 4 |
Rotation speed (rpm) | 1450 |
Insulation class | F |
Protection degree | IP68 |
Frequency (Hz) | 50 |
Voltage (V) | 380-415, 400-415 |
Power (kW) | 15 |
Power (HP) | 20 |
Max. flow rate (l/min) | 11000 |
Max. head height (m) | 12.2 |
Ebara 20 HP Wastewater Lift Pump 300DL515 Performance Data
l/min | 0 | 3000 | 4000 | 5000 | 6000 | 7000 | 8000 | 9000 | 10000 | 11000 |
m³/h | 0 | 180 | 240 | 300 | 360 | 420 | 480 | 540 | 600 | 660 |
Head (m) | 12.2 | 9.9 | 9.2 | 8.5 | 8.0 | 7.2 | 6.6 | 5.9 | 5.1 | 4.2 |
Ebara 20 HP Wastewater Lift Pump 300DL515 Dimensions
Dimensions (mm) | Weight (kg) | |||||||||
A | B | C | D | E | F | H | J | L1 | CL (m) | 395 |
1100 | 588 | 798 | 302 | 575 | 671 | 1131 | 420 | 450 | 10 |
Ebara 20 HP Wastewater Lift Pump 300DL515 Applications
- Municipal sewage and wastewater transfer
- Industrial drainage systems
- Flood control and drainage
- Wastewater treatment plants
Ebara 20 HP Wastewater Lift Pump 300DL515 Benefits
- High capacity for large volume transfer
- Durable cast iron construction
- Reliable mechanical seals for long-term use
- Suitable for submerged operation up to 7 meters
Ebara 20 HP Wastewater Lift Pump 300DL515 Price List
No. | Name | Price |
1 | Ebara 20 HP Wastewater Lift Pump 300DL515 Price | Contact us |
