Ebara 0.75 HP Submersible Borehole Pump WINNER 4N2A-10 Specifications
Ebara submersible borehole pump WINNER 4N2A-10 delivers a power output of 0.55 kW (0.75 HP). It provides a maximum flow rate of 3.3 cubic meters per hour (55 liters per minute), ensuring efficient and consistent liquid movement. This Ebara submersible pump is capable of generating a maximum head of 65.5 meters, allowing effective pumping over substantial vertical distances. Designed for submerged operation, the pump supports installation depths of up to 100 meters. It can handle liquids with temperatures up to 40°C and tolerate sand content of up to 50 ppm, ensuring reliable performance in environments with moderate particulate presence. The motor is configured with two poles and features insulation class F for dependable thermal protection. With an IP58 protection rating, the pump offers strong resistance against dust and water ingress, making it suitable for outdoor and demanding operating conditions.
| Specification | Value |
| Power (kW) | 0.55 |
| Power (HP) | 0.75 |
| Maximum Flow rate (m3/h) | 3.3 |
| Maximum Flow rate (l/min) | 55 |
| Maximum head (m) | 65.5 |
| Maximum immersion depth (m) | 100 |
| Maximum liquid temperature (°C) | 40 |
| Maximum sand content (ppm) | 50 |
| Poles | 2 |
| Insulation class | F |
| Protection degree | IP58 |
Ebara 0.75 HP Submersible Borehole Pump WINNER 4N2A-10 Applications
- Water supply systems
- Irrigation and agriculture
- Drainage and flood control
- Industrial fluid transfer
Ebara 0.75 HP Submersible Borehole Pump WINNER 4N2A-10 Benefits
- High efficiency with a powerful 0.75 HP motor
- Deep immersion capability up to 100 meters
- Durable design suitable for harsh environments
- Protection against dust and water jets (IP58)
Ebara 0.75 HP Submersible Borehole Pump WINNER 4N2A-10 Price List
| No. | Name | Price |
| 1 | Ebara 0.75 HP Submersible Borehole Pump WINNER 4N2A-10 Price | Contact us |
