Dab 50 HP Submersible Motor TR6-30 kW-400 V-T Specifications
This industrial motor delivers 37 kW (50 HP) of power, making it suitable for demanding applications. It operates at 3000 rpm and draws 80 amperes. The starting current ratio of 5.0 allows smooth and efficient startup, and the motor consumes approximately 35,714 watts during operation. This Dab submersible motor features a NEMA 6-inch flanging for secure and standardized mounting and carries an IP68 protection rating, providing strong resistance to dust and water ingress. Cooling is maintained at a flow speed of 0.5 meters per second, supporting effective temperature management during continuous operation. The motor accommodates power supply variations of +6% to –10% and can be started up to 15 times per hour, making it suitable for frequent operation. It is designed to operate at depths up to 300 meters and withstand pressures up to 60 bar.
| Specification | Value |
| Power (kW) | 37 |
| Power (HP) | 50 |
| Current (A) | 80 |
| Starting Current Ratio | 5.0 |
| P1(W) | 44578 |
| Speed (rpm) | 3000 |
| Flanging | NEMA 6″ |
| Protection Class | IP68 |
| Cooling Flow Speed (m/s) | 0.5 |
| Power Supply Tolerance | +6%/-10% |
| Max Starts (/h) | 15 |
| Max Operating Depth (m) | 300 |
| Max Operating Temperature (bar) | 60 |
| Horizontal Operation (HP) | 7.5-50 |
Dab 50 HP Submersible Motor TR6-30 kW-400 V-T Applications
- Water pumping stations
- Manufacturing machinery
- Oil and gas extraction equipment
- Marine and underwater systems
Dab 50 HP Submersible Motor TR6-30 kW-400 V-T Benefits
- High durability with IP68 protection
- Reliable performance at high depths and temperatures
- Efficient cooling system for continuous operation
- Versatile for horizontal and vertical applications
Dab 50 HP Submersible Motor TR6-30 kW-400 V-T Price List
| No. | Name | Price |
| 1 | Dab 50 HP Submersible Motor TR6-30 kW-400 V-T Price | Contact us |
