Dab 100 HP Submersible Motor TR10-75 kW-400 V-T

Dab 100 HP Submersible Motor TR10-75 kW-400 V-T Specifications

Dab submersible motor TR10-75 kW-400 V-T delivers 75 kW (100 HP) power, suitable for demanding industrial applications. It operates at a speed of 3000 rpm and features a robust flanging size of 10 inches. The device is protected with an IP58 rating, with an option for IP68, ensuring durability in harsh environments. This Dab motor can handle a maximum operating depth of 300 meters and withstand pressures up to 60 bar. The cooling system maintains a flow speed of 0.5 meters per second, promoting efficient heat dissipation. The motor’s power supply tolerance ranges from +6% to -10%, providing flexibility in various power conditions. It supports up to 8 starts per hour, making it suitable for intermittent use. Designed for horizontal operation, it can handle power levels from 100 HP to 230 HP, making it versatile for different industrial setups. The current draw is 148 amperes, and the starting current ratio is 5.4, ensuring reliable startup performance. Overall, this motor combines power, durability, and flexibility for a wide range of industrial applications, especially in environments requiring high pressure and deep water operation.

Dab 100 HP Submersible Motor TR10-75 kW-400 V-T Applications

• Underwater exploration and subsea equipment
• Heavy-duty industrial machinery
• Deep-sea oil and gas operations
• High-pressure water systems

Dab 100 HP Submersible Motor TR10-75 kW-400 V-T Benefits

• High power output for demanding tasks
• Durable protection against harsh environments
• Flexible operation with high depth and pressure tolerance
• Reliable performance with multiple start cycles
