Dab 100 HP Submersible Motor TR10-75 kW-380 V-T

Dab 100 HP Submersible Motor TR10-75 kW-380 V-T Specifications

Dab 100 HP submersible motor TR10-75 kW-380 V-T delivers 75 kW (100 HP) of power. It operates at 1500 rpm to ensure consistent and efficient performance. The unit is equipped with a 10-inch flanging interface and carries an IP58 protection rating, with an IP68 variant available upon request for environments requiring enhanced resistance to water and particulate ingress. This Dab submersible motor can be started up to eight times per hour and is engineered for submersible operation at depths of up to 300 meters, withstanding pressures of up to 60 bar. Cooling is supported by a flow speed of 0.5 meters per second, ensuring effective thermal regulation during continuous operation. The power supply tolerance range of +6% to -10% provides operational stability under varying electrical conditions. Designed for horizontal installation, the motor supports applications within the 100 HP to 230 HP range, offering flexibility across diverse industrial setups.

Specification	Value
Power (kW)	75
Power (HP)	100
Current (A)	153
Starting Current Ratio	5.4
P1 (W)	86207
Speed (rpm)	1500
Flanging	10″
Protection class	IP58 (IP68 on request)
Cooling flow speed	0.5 m/s
Power supply tolerance	+6%/-10%
Max. starts	8/h
Max operating depth	300 m
Max operating temperature	60 bar
Horizontal operation	100 HP-230 HP

Dab 100 HP Submersible Motor TR10-75 kW-380 V-T Applications

• Deep-sea drilling operations
• Industrial pumping systems
• Heavy-duty manufacturing equipment
• Marine and underwater machinery



Dab 100 HP Submersible Motor TR10-75 kW-380 V-T Benefits

• High power output for demanding tasks
• Durable protection against harsh environments
• Flexible operation with adjustable power supply tolerance
• Suitable for deep-sea and high-temperature applications



Dab 100 HP Submersible Motor TR10-75 kW-380 V-T Price List

No.	Name	Price
1	Dab 100 HP Submersible Motor TR10-75 kW-380 V-T Price	Contact us
