Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE

Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE Specifications

This product offers a robust power output with a maximum of 18 kW when using LPG and 16 kW with natural gas. It operates on a rated voltage of 380V for three-phase and 220V for single-phase setups, drawing 34.2 amps in three-phase and 27.3 amps per phase in single-phase mode. The device maintains harmonic distortion below 5%, ensuring cleaner power. It features a 38-amp main line circuit breaker for safety and runs on a single phase at 50 Hz frequency. The unit weighs approximately 590.4 pounds (267.8 kg) and measures 53 inches in length, 28.2 inches in width, and 28.4 inches in height. This Champion Generator contains two cylinders with a total displacement of 999 cc, making it suitable for various power applications. The oil capacity is 3 quarts (2.8 liters), and it uses 10W-30 oil for optimal performance.

Specification	Value
Maximum continuous power (LPG)	18 kW
Maximum continuous power (NG)	16 kW
Rated voltage	380V / 3P, 220V / 1P
Current (A)	34.2 A / 3P, 27.3 A x 3 / 1P
Main line circuit breaker	38 amp
Phase	Single
Frequency (Hz)	50
Unit weight	590.4 lb. (267.8 kg)
Size (L x W x H)	53 x 28.2 x 28.4 in. (134.7 x 71.6 x 72.1 cm)
Number of cylinders	2
Displacement (cc)	999
Oil capacity	3.0 qt (2.8 L)
Oil type	10W-30

Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE Applications

• Backup power for homes and small businesses
• Construction site power supply
• Emergency power during outages
• Powering outdoor events and activities



Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE Benefits

• High power output suitable for various needs
• Low harmonic distortion for cleaner electricity
• Durable and easy to install or move
• Safe operation with a 38-amp circuit breaker



Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE Price List

No.	Name	Price
1	Champion 16 kW Dual Fuel Gas Portable Generator 500304-3P-UAE Price	Contact us
